Air-Con 2 Zone 24000 BTU 22 SEER 230v Multi Split Air Conditioner

Save $85.20

BTU: 24000 BTU
Price:
Sale price$1,618.80 Regular price$1,704.00

Heat & Cool -Enjoy year round comfort with the ability to heat or cool your room or space. Build your multi-zone unit with compatible Outdoor and Indoor units.

  • The 24,000 BTU Outdoor unit is a high efficiency air conditioner, heater and dehumidifier all in one. Built with pro-grade materials for a long life.
  • Mix & match compatible Indoor units to complete your dual zone A/C system.

Energy Savings - With up to 22 SEER rating**, you can save money on your monthly electricity bill!

 Package Includes:
24,000 BTU Outdoor Unit
Two Compatible Indoor Units with Remotes



 Installation Items Sold Separately Quantity Needed
1/4"x3/8" Copper Lineset 25' 2 - one per Indoor Unit
Outdoor Unit Wall Bracket Stainless Steel 1 - one per Outdoor Unit
Power Cables - 10-3 gauge super service wire (For lengths over 25 feet) or 12-3 gauge super service wire (For lengths under 25 feet) 1 - one per Outdoor Unit. These cables can be found at a local hardware or electric supply store. For more info, click here
Signal Cables - 16-4 or 14-4 gauge super service wire 2 - one per Indoor Unit. These cables can be found at a local hardware or electric supply store. For more info, click here

    Note: Licensed HVAC technician required for proper installation and maintenance.

    ** This unit's AHRI Reference Number is 204462794 .

    Compatible Indoor Units Two Unit Combinations
    Wall: 9K & 12k 9 + 9
    Ducted: 9K & 12k 9 +12
    Cassettes: 9K & 12K 12 + 12



    Technology:

    CERIFICACION_INVERTER  inverter  energy star  Intertek Logo CERIFICACION_AHRI

    OUTDOOR UNIT SPECS

    OUTDOOR_24K-02

    Model
    AMSCI4H4S24
    Voltage/Frequency/Phase 208/230 - 60 Hz - Single Phase
    Cooling Capacity 24000
    Heating Capacity 24000
    Watts 1920
    Amperage 8.7
    Operating Ambient Temperature 14° F Cooling / -10° F Heating
    Outdoor Unit Dimensions 37-3/8" x 33" x 13-3/8"
    Lineset Size 1/4" & 3/8"




    9K INDOOR UNITS

    9,000 BTU COMPATIBLE UNITS

    Wall Mounted

    INDOOR_9K

    Model
    ABXEM4H4S09
    Voltage/Frequency/Phase 208/230 - 60 Hz - Single Phase
    Cooling Capacity 9000
    Heating Capacity 9000
    Watts 2638
    Amperage 0.11
    Unit Dimensions 37-3/8" x 10-3/4" x 8-1/8"
    Lineset Size 1/4" & 3/8"



    Ceiling Cassette

    INDOOR_CASSETTE_9K

    Model
    ASLEC4H4S09
    Voltage/Frequency/Phase 208/230V - 60Hz - 1 phase
    Cooling Capacity 9000
    Heating Capacity 9000
    Watts 2638
    Amperage 0.25
    Indoor Unit Dimensions 22 7/16" x 8 7/16" x 22 7/16"
    Lineset Size 1/4" & 3/8"



    Ducted Type

    INDOOR_DUCTED_9K

    Model
    ASLEK4H4S09
    Voltage/Frequency/Phase 208/230V - 60Hz - 1 phase
    Cooling Capacity 9000
    Heating Capacity 9000
    Watts 2638
    Amperage 0.25
    Indoor Unit Dimensions 35-7/8" x 7-7/2" x 17-1/2"
    Lineset Size 1/4" & 3/8"



    12K INDOOR UNITS

    12,000 BTU COMPATIBLE UNITS

    Wall Mounted


    INDOOR_9K-05
    Model
    ABXEM4H4S12
    Voltage/Frequency/Phase 208/230 - 60 Hz - Single Phase
    Cooling Capacity 12000
    Heating Capacity 12000
    Watts 3517
    Amperage 0.11
    Unit Dimensions 37-3/8" x 10-3/4" x 8-1/8"
    Lineset Size 1/4" & 3/8"



    Ceiling Cassette
    Ceiling Cassette
    Model
    ASLEC4H4S12
    Voltage/Frequency/Phase 208/230V - 60Hz - 1 phase
    Cooling Capacity 12000
    Heating Capacity 12000
    Watts 3517
    Amperage 0.25
    Indoor Unit Dimensions 22 7/16" x 8 7/16" x 22 7/16"
    Lineset Size 1/4" & 3/8"



    Ducted Type
    Ducted Type
    Model
    ASLEK4H4S12
    Voltage/Frequency/Phase 208/230V - 60Hz - 1 phase
    Cooling Capacity 12000
    Heating Capacity 12000
    Watts 3517
    Amperage 0.25
    Indoor Unit Dimensions 35-7/8" x 7-7/16" x 17-1/2"
    Lineset Size 1/4" & 3/8"






      WARRANTY



      Warranty Details

      For our full details, please visit the Air-Con International Warranty Information page.

      Already purchased our product and would like to register your unit? Please visit our Warranty Registration page.
